February 18, 2019

Understanding grid disks in Exadata

Filed under: Exadata — Sidhu @ 6:37 pm
Tags: , ,

Use of Exadata storage cells seems to be a very poorly understood concept. A lot of people have confusions about how exactly ASM makes uses of disks from storage cells. Many folks assume there is some sort of RAID configured in the storage layer whereas there is nothing like that. I will try to explain some of the concepts in this post.

Let’s take an example of an Exadata quarter rack that has 2 db and 3 storage nodes (node means a server here). Few things to note:

  • The space for binaries installation on db nodes comes from the local disks installed in db nodes (600GB * 4 (expandable to 8) configured in RAID5). In case you are using OVM, same disks are used for keeping configuration files, Virtual disks for VMs etc.
  • All of the ASM space comes from storage cells. The minimum configuration is 3 storage cells.

So let’s try to understand what makes a storage cell. There are 12 disks in each storage cell (latest X7 cells are coming with 10 TB disks). As I mentioned above that there are 3 storage cells in a minimum configuraiton. So we have a total of 36 disks. There is no RAID configured in the storage layer. All the redundancy is handled at ASM level. So to create a disk group:

  • First of all cell disks are created on each storage cell. 1 physical disk makes 1 cell disk. So a quarter rack has 36 cell disks.
  • To divide the space in various disk groups (by default only two disk groups are created : DATA & RECO; you can choose how much space to give to each of them) grid disks are created. grid disk is a partition on the cell disk. slice of a disk in other words. Slice from each cell disk must be part of both the disk groups. We can’t have something like say DATA has 18 disks out of 36 and the RECO has another 18. That is not supported. Let’s say you decide to allocate 5 TB to DATA grid disks and 4 TB to RECO grid disks (out of 10 TB on each disk, approx 9 TB is what you get as usable). So you will divide each cell disk into 2 parts – 5 TB and 4 TB and you would have 36 slices of 5 TB each and 36 slices of 4 TB each.
  • DATA disk group will be created using the 36 5 TB slices where grid disks from each storage cell constitute one failgroup.
  • Similarly RECO disk group will be created using the 36 4 TB slices.

What we have discussed above is a quarter rack scenario with High Capacity (HC) disks. There can be somewhat different configurations too:

  • Instead of HC disks, you can have the Extreme Flash (EF) configuration which uses flash cards in place of disks. Everything remains the same except the number. Instead of 12 HC disks there will be 8 flash cards.
  • With X3 I think, Oracle introduced an eighth rack configuration. In an eighth rack configuration db nodes come with half the cores (of quarter rack db nodes) and storage cells come with 6 disks in each of the cell. So here you would have only 18 disks in total. Everything else works in the same way.

Hope it clarified some of the doubts about grid disks.

January 22, 2019

ORA-04080: trigger ‘PRICE_HISTORY_TRIGGERV1’ does not exist

Filed under: Database — Sidhu @ 7:15 pm

It is actually a dumb one. I was disabling triggers in a schema and ran this SQL to generate the disable statements. (Example from here)

HR@test> select 'alter trigger '||trigger_name|| ' disable;' from user_triggers where table_name='PRODUCT';

alter trigger PRICE_HISTORY_TRIGGERv1 disable;

HR@test> alter trigger PRICE_HISTORY_TRIGGERv1 disable;
alter trigger PRICE_HISTORY_TRIGGERv1 disable
ERROR at line 1:
ORA-04080: trigger 'PRICE_HISTORY_TRIGGERV1' does not exist


WTF ? It is there but the disable didn’t work. I was in hurry, tried to connect through SQL developer and disable and it worked ! Double WTF ! Then i spotted the problem. Someone created it with one letter in the name in small. So to make it work, we need to use double quotes.

HR@test> alter trigger "PRICE_HISTORY_TRIGGERv1" disable;

Trigger altered.


One of the reasons why you shouldn’t use case sensitive names in Oracle. That is stupid.

January 12, 2019

Error while running ggsci

Filed under: GoldenGate — Sidhu @ 7:51 pm
Tags: ,

This was another issue that I faced while trying to configure GoldenGate in HA mode. ggsci was working fine after normal installation but after configuring it in HA mode and trying to run ggsci, it resulted in this:

[oragg@node2 product]$ ggsci
Oracle GoldenGate Command Interpreter for Oracle
Version OGGCORE_12.
Linux, x64, 64bit (optimized), Oracle 12c on Apr 16 2018 00:53:30
Operating system character set identified as UTF-8.
Copyright (C) 1995, 2018, Oracle and/or its affiliates. All rights reserved.
2019-01-08 16:28:37.913
CLSD: An error occurred while attempting to generate a full name. Logging may not be active for this process
Additional diagnostics: CLSU-00100: operating system function: sclsdgcwd failed with error data: -1
CLSU-00103: error location: sclsdgcwd2
GGSCI (node2) 1>

No obvious clues in the error message but little searching revealed that it had something to do with permissions. It was on Exadata so i tried to do a strace of ggsci and see if it could give some clues. There we go:

[oragg@node2 product]$ strace ggsci
mkdir("/u01/app/oracle/product/", 01777) = -1 EACCES (Permission denied)

That is the Oracle database home, GoldenGate is supposed to use. It is trying to create a directory at the mentioned path and not able to do it. There was another directory called client needed inside this. I created both of them and set the needed permissions & the sticky bit and it worked fine. It was working fine on the other node, so i could check the permissions over there and do the same on this node.

January 8, 2019

Failed to execute the command “”/u01/app/xag/bin/clsecho”

Filed under: GoldenGate — Sidhu @ 10:52 pm

I was configuring GoldenGate in HA mode by following this document. Everything worked ok but in the end while running agctl config goldengate to view the configuration of GoldenGate resource, it was failing with the following error:

[oracle@exadatadb02 ~]$ agctl config goldengate GG_TARGET
Failed to execute the command ""/u01/app/xag/bin/clsecho" -p xag -f xag -m 5080 "GG_TARGET"" (rc=134), with the message:
Oracle Clusterware infrastructure fatal error in clsecho.bin (OS PID 126367_140570897783808): Internal error (ID (:CLSB00107:)) - Error -1 (ORA-08275) determining Oracle base
/u01/app/xag/bin/clsecho: line 45: 126367 Aborted (core dumped) ${CRS_HOME}/bin/clsecho.bin "$@"
Failed to execute the command ""/u01/app/xag/bin/clsecho" -p xag -f xag -m 5081 "/u01/app/oragg/product"" (rc=134), with the message:

If you look at the error in bold it sounds kinda obvious that it is not able to figure our where the ORACLE_BASE is. But somehow it didn’t strike me at that moment. So started looking around. If we look at the command it is running, it runs clsecho. This is simply a shell script which in turn calls $CRS_HOME/bin/clsecho.bin . In the script, it sets various environment variables and that is where the problem was. There are lines like:


Nowhere in the script, it is setting the value of ORACLE_BASE. That was causing an issue. I changed the first line to set the ORACLE_BASE location and it worked fine after that. There was another issue i faced with ggsci after doing xag configuration. Will do another blog post on that.

December 26, 2018

dbca doesn’t list diskgroups

Filed under: Database,Exadata — Sidhu @ 9:01 pm
Tags: ,

This is an Exadata machine running GI version and DB version On one of the DB nodes while running dbca, it doesn’t list the diskgroups. it works fine on the other node.

I cheked the dbca trace and found that the kfod command was failing. I tried to run it manually and got the same error:

[oracle@exadb01 ~]$ /u01/app/ op=groups verbose=true
KFOD-00300: OCI error [-1] [OCI error] [Could not fetch details] [-105777048]

KFOD-00105: Could not open pfile 'init@.ora'
[oracle@exadb01 ~]$

I ran it with strace then:

[oracle@exadb01 ~]$ strace /u01/app/ op=groups verbose=true
execve("/u01/app/", ["/u01/app/", "op=groups", "verbose=true"], [/* 18 vars */]) = 0
brk(0) = 0x2641000
open("/u01/app/", O_RDONLY) = -1 EACCES (Permission denied)
geteuid() = 1003
open("/u01/app/", O_RDONLY) = 13
fcntl(13, F_SETFD, FD_CLOEXEC) = 0
lseek(13, 0, SEEK_SET) = 0
read(13, "\25\23\"\1\23\3\t\t\0\0\0\0\0\0\0\0\0\0\0\0\0\0\0\0\0\0\0\0\0\0\0\0"…, 280) = 280
lseek(13, 512, SEEK_SET) = 512
read(13, "\352\3\0\0\0\0\0\0\0\0\0\0\0\0\0\0\0\0\0\0\0\0\0\0\0\0\0\0\0\0\0\0"…, 512) = 512
lseek(13, 1024, SEEK_SET) = 1024
read(13, ".\1=\1E\1M\1X\1\352\3\0\0\0\0\0\0\0\0\0\0\0\0\0\0\0\0\0\0\0\0"…, 512) = 512
lseek(13, 1536, SEEK_SET) = 1536
read(13, "\n\0d\0\0\0D\0e\0\1\0e\0f\0\1\0\230\0g\0\1\0\306\0h\0\2\0\325\0"…, 512) = 512
fstat(1, {st_mode=S_IFCHR|0620, st_rdev=makedev(136, 3), …}) = 0
mmap(NULL, 4096, PROT_READ|PROT_WRITE, MAP_PRIVATE|MAP_ANONYMOUS, -1, 0) = 0x7f43f85f2000
write(1, "KFOD-00300: OCI error [-1] [OCI "…, 78KFOD-00300: OCI error [-1] [OCI error] [Could not fetch details] [-132605848]
) = 78

The text in bold just before the kfod error caught my attention. When I checked actually oracle user wasn’t able to read the file. The permissions looked like this:

[root@exadb01 dbs]# ls -ltr
total 20
-rw-r--r-- 1 oragrid oinstall 3079 May 14 2015 init.ora
-rw-r--r-- 1 oragrid oinstall 587 Dec 12 15:33 initbackuppfile.ora
-rw-rw---- 1 oragrid asmadmin 1656 Dec 20 14:26 ab_+ASM1.dat
-rw-rw---- 1 oragrid oinstall 1544 Dec 20 14:26 hc_+APX1.dat
-rw-rw---- 1 oragrid oinstall 1544 Dec 21 16:57 hc_+ASM1.dat
[root@exadb01 dbs]#

Whereas on node2 they were like:

[oracle@exadb02 dbs]$ ls -ltr
total 16
-rwxrwxrwx 1 oragrid oinstall 3079 Dec 12 14:52 init.ora
-rwxrwxrwx 1 oragrid oinstall 1544 Dec 21 16:57 hc_+ASM2.dat
-rw-rw---- 1 oragrid oinstall 1720 Dec 21 16:57 ab_+ASM2.dat
-rwxrwxrwx 1 oragrid oinstall 1544 Dec 21 16:57 hc_+APX2.dat
[oracle@exadb02 dbs]$

Since oracle user isn’t member of asmadmin group, it is not able to read the mentioned file. Changing the owner to oragrid:oinstall fixed the issue.
